BRUTE has designed Full Auto CR Coil Slitter Rewinding Machine that can skillfully slit coils of different materials, including cold rolled steel, and is capable of realizing high-precision slitting results. As one of the professional manufacturers in China, BRUTE slitting machine equipment has been successfully sold to many countries such as Saudi Arabia and India, welcome to contact us.
|
The Full Auto CR Coil Slitter Rewinding Machine is one of our feature product, as a professional coil process equipment manufacturer, BRUTE has been focusing on the research and development of coil slitting machine manufacturing up to 20 years of time, has a wealth of experience in production and sales, can be customized according to customer needs to design different production lines. Don't hesitate to provide us with your production requirements and we will immediately design a customized solution for you.
To produce high quality slitter cold rolled steel products, the BRUTE cold rolled steel slitting machine primarily consists of a hydraulic decoiler, slitter, and rewind machine.Steel that has been cold rolled is known as cold rolled steel. The No. 1 steel plate is subsequently rolled to the desired thickness at room temperature to create a steel plate known as cold rolling. Cold-rolled steel sheets provide improved mechanical features than hot-rolled steel sheets, including more accurate thickness measurement, a smooth, beautiful surface, and better processing capabilities. |
 |
Coil Car -- Hydraulic Decoiler -- Pinch & Pre-Straightener -- Side Guide -- High Quality Slitter -- Scrap Winder -- Loop Bridge -- Separator -- Rewinding
|
Material |
|
|
Raw Material |
Cold Rolled Steel And So On |
|
Material Thickness |
0.3-3mm |
|
Material Width Range |
1800-2000MM |
|
Coil Weight |
20Ton |
|
Coil I.D |
Φ508 mm/610mm |
|
Coil O.D |
φ1800mm（Max） |
|
Production Line |
|
|
Working Speed |
0-220M/Min |
|
Slitting Strips |
2-15 |
|
Max slit quantity |
8 pcs (3mm), 30 pcs(0.3mm) |
|
Product Precision |
±0.15MM |
|
Hydraulic decoiler and Rewinding device
Technology parements:
1. StructureSteel plate welded frame, hydraulic expansion and contraction mandrel 2. Load-bearing15T 3. Steel coil inner diameterΦ508mm 4. Steel coil outer diameterMAX: Φ1800mm 5. Unwinding arc plate structureCantilever type, four-piece curved plate structure 6. Expansion and contraction range of arc plateΦ470mm-Φ508mm 7. Feeding methodPassive feeding; 8. unwinding power11KW motor; |
 |
|
Main slitting machine
Technical Parameters
1. StructureSteel plate welded base, power gearbox, archway and frame 2. Slitting speed120m/min 3. Tool shaft diameterΦ160mm×1600mm 4. Material42CrMo 5. Cutter sizeΦ280mm×Φ160mm×15mm(Outter diameter*inner diameter*thickness) 6. Main motor powerAC75Kw 7. Mobile archway motorInstalled outside the rack, does not affect the installation of knives |
 |
|
Pre-separation frame tension machine
Technical Parameters:
1. StructureSteel plate welded base and frame 2. Quantity2 sets 3. Spacer sizeΦ100×Φ200*3 4. Spacer sizeΦ100×Φ130×＆ 5. Intermediate pressure rollervertical lift |
 |
1.Whole Solution For Coil Slitting Machine
BRUTE STEEL SLITTER can offer different solutions for the production of slitting machines according to the customer's needs. For example, according to different production materials, stainless steel and iron plate; according to different slitting requirements, adjusting the blade design; according to different speed requirements, providing double knife block to realize 220M/min high speed production.
2.Machine Quality Control
To guarantee that each stage of the production process complies with the norms and specifications, BRUTE has built a rigorous quality control method. This comprises acquiring raw materials, the manufacturing procedure, assembly, testing, etc. to make certain that the machine's components all adhere to quality standards.
Additionally, BRUTE STEEL SLITTER coil slitting machine has obtained a global CE certified certification.
3.Technical Support
（Technical Support in Saudi Arabia）
BRUTE STEEL SLITTER will arrange engineers to go abroad to install the machine at the customer's place to ensure the normal operation of the machine, and will provide all technical guidance. Exact costs to be negotiated.
